Float switch P45

Home Assistant

Float switch for applications where a float uses a magnet to make or break contact.

SKU: OT2067-C127 Article number: NB123 EAN: 4195694018533 Location: C12.07

€ 2,10 Incl. VAT (€ 1,74 Excl. VAT)

In stock (22)

30-day reflection period

1-year warranty

Ordered on weekdays before 2:00 PM, shipped today

Free returns

Float switch P45

This float operates based on a Reed switch. The magnetic field moves through the float, causing it to either make or break contact.

Max Contact Rating: 10 W
Max Switching Voltage: 100VDC
Max Switching Current: 0.5A
Max Breakdown Voltage: 220VDC
Max Carry Current: 1.0A
Max Contact Resistance: 100 mohm
Temperature Rating: -20 to 80 Celsius
Insulation Resistance: > 10
Contact Impedance: < 100 m
Float Ball Material: Polypropylene

Cable length: approx. 35cm

Dimensions
Length: 5.7cm
Width: 2.2cm
Height: 1.5cm

Reed switch
Float
5,7 x 2,2 x 1,5 cm
Cable length 35 cm

Why choose this product?

Reed switch – Works based on a reed switch.
Magnetic contact – Magnetic field makes or breaks contact.
High switching ratings – Suitable up to 100VDC and 0.5A.
Wide temperature range – Usable from -20 to 80 °C.

Specifications

Width	2,2 cm
Material	polypropylene
Length	5,7 cm
Contact resistance	100 mohm
Insulation resistance	> 10
Height	1.5 cm
Cable length	approx. 35 cm
Max. switching current	0.5A
Switching voltage	100VDC
Max Contact Rating	10 W
Max Breakdown Voltage	220VDC
Max Carry Current	1.0A
Temperature Rating	-20 80 celsius
Contact Impedance	< 100 m
