LoRa Antenna 433MHz with IPEX Connector (OT7021)

The LoRa 433MHz FPC PCB antenna is a compact and efficient solution for LoRa communication and wireless IoT applications. With 6dBi gain and omnidirectional radiation, this antenna ensures optimal signal coverage and a stable connection.

Equipped with a U.FL (IPEX) connector and a 13 cm RG1.13 cable, this antenna is easy to integrate into various LoRa devices, wireless sensors, and IoT solutions. The 3M adhesive mount provides a simple and secure installation within enclosures.

Key Features

• 433MHz frequency, ideal for LoRa and wireless communication
• 6dBi gain for strong and stable signal reception
• Omnidirectional radiation with 360-degree horizontal beamwidth
• Compact size of 45 mm x 17 mm, ideal for small spaces
• Low VSWR (≤1.5) for minimal signal loss and efficient transmission
• U.FL (IPEX) connector for easy integration
• 13 cm RG1.13 cable, flexible and compatible with various applications
• Easy 3M adhesive mount for quick installation
• Temperature resistant (-40°C ~ +80°C), suitable for industrial and outdoor applications

Technical Specifications

Antenna Specifications

• Frequency: 433 MHz
• Gain: 6dBi
• VSWR: ≤1.5
• Radiation Pattern: Omnidirectional (360° horizontal coverage)
• Input Impedance: 50Ω
• Maximum Power: 50W
• Dimensions: 45 mm x 17 mm

Connectors and Mounting

• Antenna Connector: U.FL (IPEX)
• Cable Length: 13 cm
• Cable Type: RG1.13 (customization available)
• Mounting: 3M adhesive

Environmental Specifications

• Operating Temperature: -40°C to +80°C
• Storage Temperature: -40°C to +80°C

Applications

• LoRa communication
• Wireless IoT devices
• Smart sensors and metering systems
• Industrial automation and smart city solutions
