USB Host Shield for Arduino Uno, Mega or Due (OT2062-C49)

This shield is suitable for an Arduino Uno, Arduino Mega or Arduino Due. The shield makes a USB host of the microcontroller. This makes it possible to connect a mouse or keyboard, for example. The following types of devices are supported: HID devices: keyboards, mice, etc. Game controllers: Sony PS3, Nintendo Wii, Xbox360 USB to serial converters: FTDI, PL-2303, ACM, etc. ADK supporting Android phones and tablets Mass storage devices: USB sticks, memory card readers, external hard drives, etc. Bluetooth dongles (Note! Some Bluetooth devices can draw more power than the Arduino can supply. If a Bluetooth device does not work, an external power source must be used.) The board is based on the MAX3421 chip and works with the SPI pins on the Arduino. To use the board, the USB Host Shield 2.0 library must be installed. This can also be installed via the 'library manager' in the Arduino IDE. DimensionsLength: 5.5cmWidth: 5.33cmHeight: 1.93cm
